Overview of High-Conductivity Red Copper Materials #
Product Features #
High-Quality Ingredients
All copper materials are imported high-conductivity red copper, offering superior purity and performance compared to standard market copper. This results in excellent conductivity and strong stability, enhancing the efficiency and reliability of electrical systems.
Diverse Options
- Bare copper (pure red copper): Ideal for standard electrical applications.
- Plated bronze: Resistant to oxidation and corrosion, suitable for humid or high-salt environments.
Complete Specifications & Sufficient Stock
- Common sizes and models are kept in stock to support a wide range of engineering needs.
- Efficient inventory management helps reduce lead times and accelerates installation and delivery.
Fast Delivery
- Flexible production and inventory systems enable rapid dispatch to meet urgent project requirements.
Customization
- Special size, alloy, or processing requirements can be accommodated, including assistance with importing unique copper materials for high-end or non-standard applications.
Technical Specifications #
| Item | T (mm) | W (mm) | L (m) | Corners |
|---|---|---|---|---|
| 1 | 2 | 10 | 3 | □ |
| 2 | 12 | |||
| 3 | 15 | |||
| 4 | 20 | |||
| 5 | 3 | 12 | 3 | □ |
| 6 | 15 | |||
| 7 | 20 | 5 | ||
| 8 | 25 | |||
| 9 | 30 | |||
| 10 | 40 | |||
| 11 | 100 | |||
| 12 | 120 | |||
| 13 | 150 | |||
| 14 | 200 | ○ | ||
| 15 | 4 | 20 | 5 | □ |
| 16 | 25 | |||
| 17 | 40 | |||
| 18 | 50 | □○ | ||
| 19 | 60 | □ | ||
| 20 | 90 | |||
| 21 | 110 | |||
| 22 | 150 | ○ | ||
| 23 | 200 | |||
| 24 | 5 | 15 | 5 | □ |
| 25 | 20 | □○ | ||
| 26 | 25 | |||
| 27 | 30 | |||
| 28 | 40 | |||
| 29 | 50 | |||
| 30 | 60 | |||
| 31 | 75 | □ | ||
| 32 | 80 | □○ | ||
| 33 | 100 | □ | ||
| 34 | 120 | □○ | ||
| 35 | 125 | |||
| 36 | 150 | □ | ||
| 37 | 200 | |||
| 38 | 6 | 20 | 5 | □ |
Frequently Asked Questions #
Q1: What are the standard copper bar lengths?
A1: For 5T x 15W (inclusive), the length is 3 meters; other sizes are 5 meters.
Q2: What are the width and thickness specifications for bronze ranking?
A2: 2T~3T x 12W~30W, 5T~10T x 15W~300W. For larger sizes, please inquire by phone.
Q3: Can bronze plating be silvered?
A3: Yes, but the length must be within 3 meters.
Q4: How is shipping cost calculated?
A4: Free shipping for orders over 1000KG; for orders under 1000KG, shipping is quoted based on delivery location.
Q5: What are the delivery options?
A5: Sales are available via cash or pre-order. In-stock items are delivered within 1–3 days. Special cases are handled separately.
